Rockwell Automation Publication 5069-UM003B-EN-P - January 2020 67
Compact 5000 I/O Serial Module Features Chapter 3
DF1 Slave Parameters
DF1 Radio Modem Parameters
For Example MSG Control Blocks, see page 147.
Table 17 - DF1 Slave Configuration Parameters
Parameter Definition Available Options
Station Address Station address of the channel. • 0…254
Transmit Retries Maximum number of times Slave can retry sending message
to Master.
• 0…127 (default = 3)
Slave Poll Timeout Maximum time Slave can wait for polling from Master when message
is sent from Slave.
• 0…32,767 (x20 ms) (default = 3000)
EOT Suppression Select whether to suppress sending EOT packets in response
to poll.
• 0 = Do Not Suppress (default)
•1 = Suppress
Error Detection Detects error protocols. • 0 = BCC
• 1 = CRC (default)
Enable Duplicate Detection When enabled, duplicate messages are acknowledged and discarded. • 0 = Disabled
• 1 = Enabled (default)
Table 18 - DF1 Radio Modem Configuration Parameters
Parameter Definition Available Options
Station Address Station address of the channel. • 0…254
Enable Store and Forward Determine whether Store and Forward (bit) is enabled. • 0 = Disabled (default)
•1 = Enabled
Error Detection Detects error protocols. • 0 = BCC
• 1 = CRC (default)
Enable Duplicate Detection When enabled, duplicate messages are acknowledged and
discarded.
• 0 = Disabled (default)
•1 = Enabled
