Chapter 3 Compact 5000 I/O Serial Module Features
DF1 Point to Point Parameters
DF1 Master Parameters
Table 15 - DF1 Point to Point Configuration Parameters
Parameter Definition Available Options
Station Address Station address of the channel. • 0…254
NAK Receive Limit Maximum number the module can receive NAK for each message. • 0…255 (default = 3)
ENQ Transmit Limit Maximum number the module can send ENQ for each message. • 0…255 (default = 3)
ACK Timeout Maximum time the module can wait for ACK for each message. • 1…32,767 (x20 ms) (default = 50)
•0 = Disabled (Wait Forever)
Embedded Responses Autodetect Embedded Responses cause the module to use embedded
responses only if an embedded response from the serial module is
received by the module.
Enabled Embedded Responses let the module send embedded
responses within packets.
• 0 = Autodetect
•1 = Enabled
Receive Termination Delimiter 1 Configure the channel's receive termination delimiter. • 8 bit $00…$FF (default = $0D )
Receive Termination Delimiter 2 Configure the channel's receive termination delimiter. • 8 bit $00…$FF ($FF = disabled)
Error Detection Detects error protocols. • 0 = BCC
• 1 = CRC (default)
Enable Duplicate Detection When enabled, duplicate messages are acknowledged and discarded. • 0 = Disabled
• 1 = Enabled (default)
Table 16 - DF1 Master Configuration Parameters
Parameter Definition Available Options
Station Address Station address of the channel. • 0…254
Transmit Retries Maximum number of times Master can retry sending message to Slave. • 0…127 (default = 3)
ACK Timeout Maximum time the module can wait for ACK for each message. • 1…32,767 (x20 ms) (default = 50)
• 0 = Disabled (Wait Forever)
Reply Message Wait Minimum time between receiving ACK and sending Poll to Slave.
Adjust this value to meet Slave response preparation time.
• 1…65,535 (x20 ms) (default = 5)
• 0 = Disabled (Wait Forever)
Error Detection Detects error protocols. • 0 = BCC
• 1 = CRC (default)
Enable Duplicate Detection When enabled, duplicate messages are acknowledged and discarded. • 0 = Disabled
• 1 = Enabled (default)
