Rockwell Automation Publication 5069-UM003B-EN-P - January 2020 7
Preface
This manual describes how to use Compact 5000™ I/O serial module in
Logix 5000™ systems.
Make sure that you are familiar with the following:
• Use of a Logix 5000™ controller
• Use of an EtherNet/IP™ network, if the serial module is installed in a
remote location that is accessible via the EtherNet/IP network.
• Studio 5000 Logix Designer® environment.
Summary of Changes
IMPORTANT The Compact 5000 I/O Serial module is only compatible with the
following controllers:
• CompactLogix™ 5380
• Compact GuardLogix® 5380
• CompactLogix 5480
• ControlLogix® 5580
• GuardLogix® 5580
Topic Page
Moved Controller software from operation chapter to overview chapter 12
Added Compact 5000 I/O modules table 12
Added Types of modules 13
Moved Local I/O or Remote I/O modules from operation chapter to overview chapter 15
Updated Construct a System topic with new text 18
Moved 5069-ARM Address Reserve Module after Construct a System 20
Updated Additional information for Compact 5000 I/O modules 21
Moved 5069-FPD Field Potential Distributor after Power the Module 22
Updated Additional information for Compact 5000 I/O modules 22
Moved Modbus Master Functions under Modbus Master Data Exchange 38
Added DF1 protocols 41
Added DF1 Data Exchange 44
Added DH-485 Data Exchange 45
Added DF1 Parameters 72
Added DH-485 Parameters 80
Added channel configuration for DF1 Point to Point 101
Added channel configuration for DF1 Master 103
Added channel configuration for DF1 Slave 105
Added channel configuration for DF1 Radio Modem 106
Added channel configuration for DH-485 107
Added DF1 sample code configuration 135
