Rockwell Automation Publication 5069-UM003B-EN-P - January 2020 15
Chapter 2
Compact 5000 I/O Serial Module Operation
Ownership
Every I/O module in a Logix 5000™ control system must be owned by a
controller, also known as the owner-controller. When the Compact 5000 I/O
modules are used in a Logix 5000 control system, the owner-controller performs
the following:
• Stores configuration data for every module that it owns.
• Can reside in a location that differs from the Compact 5000 I/O modules.
• Sends the I/O module configuration data to define module behavior and
begin operation in the control system.
Each Compact 5000 I/O serial module must continuously maintain
communication with its owner-controller during normal operation.
Topic Page
Ownership 15
Construct a System 16
5069-ARM Address Reserve Module 18
Power the Module 19
5069-FPD Field Potential Distributor 20
Configure Modules 21
