Page #17 background image
Rockwell Automation Publication 5069-UM003B-EN-P - January 2020 17
Compact 5000 I/O Serial Module Operation Chapter 2
Remote I/O modules
Complete the following:
1. Install a controller that is compatible with the remote Compact 5000
I/O modules.
2. Install an EtherNet/IP™ network.
3. Connect the controller to the network.
4. Install a Compact 5000 EtherNet/IP adapter.
5. Connect the adapter to the network.
6. Install the Compact 5000 I/O modules to the right of the adapter.
7. Install the end cap on the last module in the system.
IMPORTANT Remember, you must use a Compact GuardLogix 5380
controller or GuardLogix 5580 controller if the set of remote
Compact 5000 I/O modules include safety modules.
For more information on controller compatibility,
see Controller and Software Compatibility on page 10
.
IMPORTANT If serial module is included, you must use AENTR
IMPORTANT The end cap in a CompactLogix 5380, CompactLogix 5480, or
Compact GuardLogix 5380 control system covers the exposed
interconnection on the last module on the DIN rail.
If you do not install an end cap on the last module on the DIN rail,
equipment damage or injury can occur.
