Programming Example Appendix C
Example MSG
Control Blocks
The following is coding examples to create MSG Read and Write control blocks:
• Logix write message to another Logix controller example.
• Read MSG from a Logix to a Logix Controller example.
• Write MSG from a logix to a PLC-5 or SLC 500 controller example.
• Read MSG from a Logix to a PLC-5 or SLC 500 controller example.
• Write MSG instruction from a Logix to an SLC or MicroLogix controller
example.
• Read MSG instruction from a Logix to an SLC or MicroLogix Controller
Figure 60 - [1] 5069-SERIAL/A SerialR2 .
Path (out serial port)
to station (254).
