Appendix A Module Tags
Input Tags
Output Tags
Table 34 - DF1 Master Input Tags
Name Data Type Definition Valid Values
Ix.DF1.RunMode BOOL Channel’s operating state • 0 = Idle
•1 = Run
Ix.DF1.ConnectionFaulted BOOL Indicates if a connection is running.
The module sets this tag to 0 when connected. If the module is not
connected, it changes the tag to 1.
• 0 = Connection running
• 1 = Connection not running
Ix.DF1.DiagnosticActive BOOL Indicates if any diagnostics are active or if the prognostics threshold
is reached.
• 0 = No diagnostics active
• 1 = One or more diagnostics are active or the
prognostics threshold is reached
Ix.DF1.DiagnosticSequenceCount SINT Increments for each time a distinct diagnostic condition is detected,
and when a distinct diagnostic condition transitions from detected
to not detected.
Set to zero by product reset or power cycle. Wraps from 255 (-1) to 1
skipping zero.
• -128…+127
The value of 0 is skipped except during module
power-up.
Ix.DF1.CTS BOOL Indicates whether the CTS is active. • 0 = Inactive
•1 = Active
Ix.DF1.RTS BOOL Indicates whether the RTS is active. • 0 = Inactive
•1 = Active
Ix.DF1.DSR BOOL Indicates whether the DSR is active. • 0 = Inactive
•1 = Active
Ix.DF1.DCD BOOL Indicates whether the DCD is active. • 0 = Inactive
•1 = Active
Ix.DF1.DTR BOOL Indicates whether the DTR is active. • 0 = Inactive
•1 = Active
Ix.DF1.MsgProcessing BOOL Determine if instruction message is processing. • 0 = Not Processing
• 1 = Processing
Ix.DF1Master.ActiveStation SINT (32) Determine if station is active. • 0 = Inactive
•1 = Active
Ix.DF1Master.PriorityPollError BOOL Shows if there was a priority polling error. • 0 = Non-occurrence
• 1 = Occurrence
Ix.DF1Master.NormalPollError BOOL Shows if there was a normal polling error. • 0 = Non-occurrence
• 1 = Occurrence
Ix.DF1Master.PollGroupSizeError BOOL Shows if the Normal Poll Group size is greater than the Max Normal
Poll Node.
• 0 = Non-occurrence
• 1 = Occurrence
Ix.DF1Master.LatestPriorityPollNode INT Address of Priority Poll Node currently being polled. • -32768…+32767
Ix.DF1Master.LatestNormalPollNode INT Address of Normal Poll Node currently being polled. • -32768…+32767
Table 35 - DF1 Master Output Tags
Name Data Type Definition Valid Values
Ox.DF1Master.MaxPriorityPollNode INT Defines the maximum number of nodes in the Priority Poll Node. • -32768…+32767
Ox.DF1Master.MaxNormalPollNode INT Defines the maximum number of nodes in the Normal Poll Node. • -32768…+32767
Ox.DF1Master.PollingListUpdateID SINT This ID is incremented when you want to update the polling list in the serial module. • -128…+127
Ox.DF1Master.PriorityPollNode
(1)
INT[N] Defines the poll sequence the DF1 Master polls for priority node. –
Ox.DF1Master.NormalPollNode
(1)
INT[M] Defines the poll sequence the DF1 Master polls for normal node. –
(1) If you configure the polling in the module definition, there will be two more tag array generated. The array is dynamically generated depending on what you configure in the definition.
