Rockwell Automation Allen-Bradley Compact 5000 Series User Manual

Rockwell Automation Publication 5069-UM003B-EN-P - January 2020 141
Appendix C
Programming Example
Generic ASCII Sample Code
The following images show sample code for Generic ASCII Transmit data and
Generic ASCII Receive data.
Transmit and Receive Channel Configurations
The following image shows the Generic ASCII Transmit Configuration.
The following image shows the Generic ASCII Receive Configuration
Topic Page
Generic ASCII Sample Code 141
Modbus Master Command List 144
Modbus Slave Address Mapping Table 144
Modbus Sample Code Configuration Example 144
