Rockwell Automation Publication 1426-UM001J-EN-P - August 2019 139
Logging Chapter 6
Data Log Parameter List
Table 16 - Data Log Parameter List
Parameter
Number
Parameter Tag Name Units
0None
1 V1_N_Volts V
2 V2_N_Volts V
3 V3_N_Volts V
4 VGN_N_Volts V
5 Avg_V_N_Volts V
6 V1_V2_Volts V
7 V2_V3_Volts V
8 V3_V1_Volts V
9 Avg_VL_VL_Volts V
10 I1_Amps A
11 I2_Amps A
12 I3_Amps A
13 I4_Amps A
14 Avg_Amps A
15 Frequency_Hz Hz
16 L1_kW kW
17 L2_kW kW
18 L3_kW kW
19 Total_kW kW
20 L1_kVAR kVAR
21 L2_kVAR kVAR
22 L3_kVAR kVAR
23 Total_kVAR kVAR
24 L1_kVA kVA
25 L2_kVA kVA
26 L3_kVA kVA
27 Total_kVA kVA
28 L1_True_PF %
29 L2_True_PF %
30 L3_True_PF %
31 Avg_True_PF %
32 L1_Disp_PF %
33 L2_Disp_PF %
34 L3_Disp_PF %
35 Avg_Disp_PF %
36 L1_PF_Lead_Lag_Indicator -
