140 Rockwell Automation Publication 1426-UM001J-EN-P - August 2019

Chapter 6 Logging

37 L2_PF_Lead_Lag_Indicator -

38 L3_PF_Lead_Lag_Indicator -

39 Total_PF_Lead_Lag_Indicator -

40 V1_Crest_Factor -

41 V2_Crest_Factor -

42 V3_Crest_Factor -

43 V1_V2_Crest_Factor -

44 V2_V3_Crest_Factor -

45 V3_V1_Crest_Factor -

46 I1_Crest_Factor -

47 I2_Crest_Factor -

48 I3_Crest_Factor -

49 I4_Crest_Factor -

50 V1_IEEE_THD_% %

51 V2_IEEE_THD_% %

52 V3_IEEE_THD_% %

53 VGN_IEEE_THD_% %

54 Avg_IEEE_THD_V_% %

55 V1_V2_IEEE_THD_% %

56 V2_V3_IEEE_THD_% %

57 V3_V1_IEEE_THD_% %

58 Avg_IEEE_THD_V_V_% %

59 I1_IEEE_THD_% %

60 I2_IEEE_THD_% %

61 I3_IEEE_THD_% %

62 I4_IEEE_THD_% %

63 Avg_IEEE_THD_I_% %

64 V1_IEC_THD_% %

65 V2_IEC_THD_% %

66 V3_IEC_THD_% %

67 VGN_IEC_THD_% %

68 Avg_IEC_THD_V_% %

69 V1_V2_IEC_THD_% %

70 V2_V3_IEC_THD_% %

71 V3_V1_IEC_THD_% %

72 Avg_IEC_THD_V_V_% %

73 I1_IEC_THD_% %

74 I2_IEC_THD_% %

75 I3_IEC_THD_% %

Table 16 - Data Log Parameter List (continued)

Parameter

Number

Parameter Tag Name Units

Main Page

Rockwell Automation Allen-Bradley PowerMonitor 5000 Unit - Page 140
