Rockwell Automation Allen-Bradley PowerMonitor 5000 Unit User Manual

22 Rockwell Automation Publication 1426-UM001J-EN-P - August 2019
Chapter 2 Install the PowerMonitor 5000 Unit
Figure 6 - Diagram V3 - 3-phase, 4-wire Wye, or Impedance Grounded Wye with PTs (No Neutral
PT)
Figure 7 - Diagram V4 - 3-phase, 4-wire Impedance Grounded Wye with Line and Neutral PTs
Metering_Mode = Wye
V1
V2
VG
V3
VN
PowerMonitor 5000
Fuses (by user)
PTs (by user)
L1 L2 L3 N
Line
Ground
Ground
Load
(1) Fuse in neutral connection is required for impedance grounded systems.
(1)
Metering_Mode = Wye
V1
V2
VG
V3
VN
PowerMonitor 5000
Fuses (by user) PTs (by user)
L1 L2 L3 N
Line
Load
Ground
Ground
Ground
