416 Rockwell Automation Publication 1426-UM001J-EN-P - August 2019
Appendix A PowerMonitor 5000 Unit Data Tables
PowerQuality.IEEE519_ Results (M6 and M8 model)
The PowerMonitor 5000 M6 and M8 models return short- and long-term
rolling average harmonic distortion data for the fundamental and the first 40
harmonic frequencies. These results are presented in six similar data tables.
These tables share the following properties.
The IEEE519 Results data tables share a common structure. In the data table
template shown, substitute the following into the Data Table Name and Tag
Name strings to obtain the specific names:
• For ‘<CH>’, substitute ‘CH1’, ‘CH2’, or ‘CH3’.
• For ‘<Term>’, substitute ‘ShortTerm’ or ‘LongTerm’.
For example, the tag CH3_5th_Harmonic_IEEE519_ShortTerm in the
PowerQuality.IEEE519_CH3 _ShortTerm_Results table returns the short-
term 5th harmonic value for Channel 3.
Table 202 - Table Properties
Data Table Name CIP Instance
Number
PCCC File No.
PowerQuality.IEEE519_CH1_ShortTerm_Results 895 F104
PowerQuality.IEEE519_CH2_ShortTerm_Results 896 F105
PowerQuality.IEEE519_CH3_ShortTerm_Results 897 F106
PowerQuality.IEEE519_CH1_LongTerm_Results 898 F107
PowerQuality.IEEE519_CH2_LongTerm_Results 899 F108
PowerQuality.IEEE519_CH3_LongTerm_Results 900 F109
No. of Elements 44
Length in Words 88
Data Type Real
Data Access Read Only
IMPORTANT Channel assignments are based on the value of the tag
IEEE519_Compliance_Parameter found in the Configuration.PowerQuality
table.
IEEE519_Compliance_Parameter Channel 1 Channel 2 Channel 3
0 = Current I1 I2 I3
1 = Voltage (Wye, Split Phase, and
Single Phase)
V1-N V2-N V3-N
1 = Voltage (Delta) V1-V2 V2-V3 V3-V1
