Rockwell Automation Allen-Bradley PowerMonitor 5000 Unit User Manual

Rockwell Automation Publication 1426-UM001J-EN-P - August 2019 327
PowerMonitor 5000 Unit Data Tables Appendix A
Configuration.PowerQuality
Table 78 - Table Properties
CIP Instance Number 815
PCCC File Number F24
No. of Elements 50
Length in Words 100
Data Type Real
Data Access Read/Write
Table 79 - Configuration.PowerQuality Data Table
Element
Number
Type Tag Name Description Default Range
0 Real Sag1_Trip_Point_% The percent of Nominal System Voltage that creates a level 1 sag
condition.
0 0.00…100.00
1 Real Sag1_Hysteresis_% The percent of hysteresis for sag 1 condition. 2 0.00…10.00
2 Real Sag2_Trip_Point_% The percent of Nominal System Voltage that creates a level 2 sag
condition.
0 0.00…100.00
3 Real Sag2_Hysteresis_% The percent of hysteresis for sag 2 condition. 2 0.00…10.00
4 Real Sag3_Trip_Point_% The percent of Nominal System Voltage that creates a level 3 sag
condition.
0 0.00…100.00
5 Real Sag3_Hysteresis_% The percent of hysteresis for sag 3 condition. 2 0.00…10.00
6 Real Sag4_Trip_Point_% The percent of Nominal System Voltage that creates a level 4 sag
condition.
0 0.00…100.00
7 Real Sag4_Hysteresis_% The percent of hysteresis for sag 4 condition. 2 0.00…10.00
8 Real Sag5_Trip_Point_% The percent of Nominal System Voltage that creates a level 5 sag
condition.
0 0.00…100.00
9 Real Sag5_Hysteresis_% The percent of hysteresis for sag 5 condition. 2 0.00…10.00
10 Real Swell1_Trip_Point_% The percent of Nominal System Voltage that creates a level 1 swell
condition.
200 100.00…200.00
11 Real Swell1_Hysteresis_% The percent of hysteresis for swell 1 condition. 2 0.00…10.00
12 Real Swell2_Trip_Point_% The percent of Nominal System Voltage that creates a level 2 swell
condition.
200 100.00…200.00
13 Real Swell2_Hysteresis_% The percent of hysteresis for swell 2 condition. 2 0.00…10.00
14 Real Swell3_Trip_Point_% The percent of Nominal System Voltage that creates a level 3 swell
condition.
200 100.00…200.00
15 Real Swell3_Hysteresis_% The percent of hysteresis for swell 3 condition. 2 0.00…10.00
16 Real Swell4_Trip_Point_% The percent of Nominal System Voltage that creates a level 4 swell
condition.
200 100.00…200.00
17 Real Swell4_Hysteresis_% The percent of hysteresis for swell 4 condition. 2 0.00…10.00
18 Real Capture_Pre_Event_Cycles The pre-event cycles for waveform capture 5 5…10
19 Real Capture_Post_Event_Cycles The post-event cycles for waveform capture 15 2…30
20 Real Relative_Setpoint_Intvl_m The interval setting in minutes for the rolling average of all
relative setpoints.
60 1…1440
21 Real IEEE1159_Parameter_Hysteresis_% The percent of hysteresis for IEEE1159 output parameters. 2 0.00…10.00
22 Real IEEE1159_Imbalance_Averaging_Intvl_m The rolling average interval for Imbalance in minutes 15 15…60
