Reference Manual
00809-0100-4360, Rev BA
August 2008
Rosemount 1151
2-22
No calibration equipment is required to configure the LCD Display, but
between 4 and 20 mA must be flowing through the loop. The actual value of
the current is not significant. In addition, meter configuration does not affect
the transmitter/loop current. Use the following meter configuration procedure
to properly configure the LCD Display:
Remove the Cover
1. Unscrew the retaining ring shown in Figure 2-12 and lift the transparent
cover off of the housing.
NOTE
The LCD Display time-out is approximately 16 seconds. If keys are
not pressed within this period, the indicator reverts to reading the
current signal.
Position the Decimal Point and Select the Meter Function
2. Press the left and right configuration buttons simultaneously and release
them immediately.
3. To move the decimal point to the desired location, press the left
configuration button.
4. To scroll through the mode options, press the right configuration button
repeatedly until the desired mode is displayed.
See Table 2-3.
