Reference Manual
00809-0100-4809, Rev DA
Appendix A: Specifications and Reference Data
September 2015
91
Specifications and Reference Data
Opposite side support or packing gland D 1-7
0
No opposite side support or packing gland (Required for Pak-Lok and Flange-Lok
models)
• • ★
Opposite side support – required for flanged models
C NPT threaded opposite support assembly – extended tip • • ★
D Welded opposite support assembly – extended tip • • ★
Packing gland – required for Flo-Tap models
Packing gland material
Rod material Packing material
J
(4)
Stainless Steel packing gland/cage nipple Carbon Steel PTFE • •
K
(4)
Stainless Steel packing gland/cage nipple Stainless Steel PTFE • •
L
(4)
Stainless Steel packing gland/cage nipple Carbon Steel Graphite • •
N
(4)
Stainless Steel packing gland/cage nipple Stainless Steel Graphite • •
R Alloy C-276 packing gland/cage nipple Stainless Steel Graphite • •
Isolation valve for Flo-Tap models
0
(2)
Not applicable or customer supplied • • ★
1 Gate valve, Carbon Steel • •
2 Gate valve, Stainless Steel • •
5 Ball valve, Carbon Steel • •
6 Ball valve, Stainless Steel • •
Temperature measurement
T
(5)
Integral RTD – not available with flanged model greater than class 600# • • ★
0
(6)
No temperature sensor • • ★
R
(5)
Remote thermowell and RTD • •
Transmitter connection platform
3
Direct-mount, Integral 3-valve Manifold– not available with flanged model greater than
class 600
• • ★
5
Direct -mount, 5-valve Manifold – not available with flanged model greater than class
600
• • ★
7 Remote-mount NPT connections (
1
/2-in. FNPT) • • ★
6
Direct-mount, High Temperature 5-valve Manifold – not available with flanged model
greater than class 600
• •
Table 1. Rosemount 3051SFA Annubar Flowmeter Ordering Information
★ The Standard offering represents the most common options. The starred options (★) should be selected for best delivery.
__The Expanded offering is subject to additional delivery lead time.
