Rosemount 8712
Viewing the 8714i Meter Verification Results
Depending on the method used to view the results, they will be displayed in
either a menu structure, as a method, or in the report format. When using the
HART Field Communicator, each individual component can be viewed as a
menu item. When using the LOI, the parameters are viewed as a method
using the left arrow key to cycle through the results. In AMS the calibration
report is populated with the necessary data eliminating the need to manually
complete the report found on page C-16.
NOTE
When using AMS there are two possible methods that can be used to print the
report.
Method one involves taking a PrntScrn picture of the 8714i Report tab on the
status screen and pasting it into a word processing program. The PrntScrn
button will capture all items on the screen so the image will need to be
cropped and resized in order to get only the report.
Method two involves using the print feature within AMS while on the status
screen. This will result in a printout of all of the information stored on the
status tabs. Page two of the report will contain all of the necessary calibration
verification result data.
The results are displayed in the following order:
Test Condition
Review the test condition that the 8714i Meter Verification test was performed
under.
Test Criteria
Review the test criteria used to determine the results of the calibration
verification tests.
8714i Result
Displays the overall result of the 8714i Meter Verification test as either a Pass
or Fail.
Simulated Velocity
Displays the simulated velocity used to verify the transmitter calibration.
HART Fast Keys 1, 2, 3, 3, 2, 1
LOI Key XMTR INFO
AMS Context Menu, Device Diagnostics, 8714i Report
HART Fast Keys 1, 2, 3, 3, 2, 2
LOI Key XMTR INFO
AMS Context Menu, Device Diagnostics, 8714i Report
HART Fast Keys 1,2,3,3,2,3
LOI Key XMTR INFO
AMS Context Menu, Device Diagnostics, 8714i Report
HART Fast Keys 1,2,3,3,2,4
LOI Key XMTR INFO
AMS Context Menu, Device Diagnostics, 8714i Report
