Reference Manual
00809-0100-4664, Rev BA
January 2010
Rosemount 8712
C-12
Actual Velocity
Displays the velocity measured by the transmitter during the transmitter
calibration verification process.
Velocity Deviation
Displays the deviation in the actual velocity compared to the simulated
velocity in terms of a percentage. This percentage is then compared to the
test criteria to determine if the transmitter is within calibration limits.
Transmitter Calibration Verification
Displays the results of the transmitter calibration verification test as either a
Pass or Fail.
Sensor Calibration Deviation
Displays the deviation in the sensor calibration. This value tells how much the
sensor calibration has shifted from the original baseline signature. This
percentage is compared to the test criteria to determine if the sensor is within
calibration limits.
Sensor Calibration Verification
Displays the results of the sensor calibration verification test as either a Pass
or Fail.
Coil Circuit Verification
Displays the results of the coil circuit health check as either a Pass or Fail.
Electrode Circuit Verification
Displays the results of the electrode circuit health check as either a Pass or
Fail.
HART Fast Keys 1,2,3,3,2,5
LOI Key XMTR INFO
AMS Context Menu, Device Diagnostics, 8714i Report
HART Fast Keys 1,2,3,3,2,5
LOI Key XMTR INFO
AMS Context Menu, Device Diagnostics, 8714i Report
HART Fast Keys 1,2,3,3,2,6
LOI Key XMTR INFO
AMS Context Menu, Device Diagnostics, 8714i Report
HART Fast Keys 1,2,3,3,2,7
LOI Key XMTR INFO
AMS Context Menu, Device Diagnostics, 8714i Report
HART Fast Keys 1,2,3,3,2,8
LOI Key XMTR INFO
AMS Context Menu, Device Diagnostics, 8714i Report
HART Fast Keys 1,2,3,3,2,9
LOI Key XMTR INFO
AMS Context Menu, Device Diagnostics, 8714i Report
HART Fast Keys 1,2,3,3,2,10 (To get to this value, the down arrow must be used to scroll
through the menu list)
LOI Key XMTR INFO
AMS Context Menu, Device Diagnostics, 8714i Report
