Tube Cal No. Identifies the calibration number when using Rosemount sensors, or other manufacturers’ sensors calibrated
at the Rosemount factory
Tube Size Specifies the sensor size and identifies the corresponding maximum flow (0.1 - through 80-inch line sizes)
Units Specifies the desired units:
Gal/Min Liters/Min
ImpGal/Min CuMeter/Hr
Ft/Sec Meters/Sec
Special (user defined)
For a complete list of available units, see Table 3-3 on page 3-9
Auxiliary Functions Function
Run 8714i
Operating Mode
Coil Pulse Mode
Flow rate Display
Totalizer Display
Totalizer Units
Signal Processing
Special Units
Process Density
DI/DO 1 Config
Digital Output 2
Flow Limit 1
Flow Limit 2
Totalizer Limit
Diagnostic Status Alert
Reverse Flow Enable
Licensed Options
License Key
Diagnostics Enable
8714i Setup
Re-signature Sensor
Recall Last Signature
Empty Pipe
Universal Auto Trim
Low Flow Cutoff
Pulse Width
Analog Output Zero
Analog Output Test
Pulse Output Test
Transmitter Test
4–20 mA Output Trim
Auto Zero
Electronics Trim
Options
Runs the meter verification diagnostic
Normal or Filter
5 or 37 Hz
Flow–% Span, Flow–Totalize, %Span–Totalize
Forward–Reverse or Net–Gross
Configure the totalizer units of measure
On/Off
Volume units, base volume units, conversion, time base, rate units
Required for units of mass flow
Configure Auxiliary Channel 1
Configure Auxiliary Channel 2
Configure Flow Limit 1 Alert
Configure Flow Limit 2 Alert
Configure Totalizer Limit Alert
Configure Diagnostic Status Alert
Reverse Flow/Zero Flow
On/Off
Field license advanced functionality
Turn diagnostics On/Off
Configure test criteria parameters
Base line sensor characteristics
Recall previous signature values
Configure empty pipe diagnostic parameters
In-process Sensor Calibration
0.01 ft/s to 1 ft/s
Pulse Width
4 mA Value
Analog Output Loop Test
Pulse Output Loop Test
Test the Transmitter
Adjust the 4–20 mA Output
Zero Sensor for 37 Hz Coil Drive Operation
Transmitter Calibration
Analog Output Range Sets the desired 20 mA point – must set the sensor size first
Pulse Output Scaling Sets one pulse to a selectable number of volume units – must set the sensor size first
Damping Sets response time (single pole time constant), in seconds, to a step change in flow rate
Transmitter Information Allows you to view and change useful information about the transmitter and sensor
Empty Pipe Tuning Allowable range 3.0 - 2000.0
Table 3-2. LOI Data Entry Keys and Functions
