Rosemount Model 8732C Integral Mount Magnetic Flowmeter System
1-2
SYSTEM DESCRIPTION
A complete magnetic flowmeter system consists of two components: the
Rosemount Model 8732C microprocessor-based integral-mount magnetic
flowmeter transmitter, and a Rosemount Model 8705 or 8711 flowtube.
The flowtube is installed in-line with process piping, either vertically or
horizontally. Coils located on opposite sides of the flowtube create a
magnetic field, and conductive liquid moving through the magnetic
field generates a voltage that is detected by two electrodes.
The transmitter controls the generation of the magnetic field and
senses the voltage detected by the electrodes. Based on the sensed
voltage, the transmitter calculates a flow rate and produces analog
and frequency output signals proportional to this flow rate.
SAFETY MESSAGES
Procedures and instructions in this manual may require special
precautions to ensure the safety of the personnel performing the
operations. Refer to the safety messages listed at the beginning of
each section before performing any operations.
