Section
4-1
4 Transmitter Functions
INTRODUCTION
The Model 8732C features a full range of software functions for
configuration of output from the transmitter. Software
functions are accessed through the LOI (see Section 3: Local
Operator Interface), a HART-based communicator
(see Appendix A: HART Communicator), or a control system.
Configuration variables may be changed at any time, and specific
instructions are provided through on-screen instructions.
Set-up Parameters Page
Basic Configuration 4-4
Special Units Configuration 4-5
Analog Output Configuration 4-6
Digital Output Configuration 4-8
Totalizer Configuration 4-11
Noise Reduction 4-12
Calibration 4-14
Transmitter Information Configuration 4-15
Multidrop Communications 4-18
