Rosemount 8732C - HART Fast Key Sequence

A-3
Appendix A
TABLE A-1. HART Fast Key
Sequences for the Model 8732C.
Function HART Fast Key
AO Alarm Type 1, 4, 3, 1, 4
Analog Output 1, 1, 3
Analog Output Range (URV) 1, 3, 3
Analog Output Zero (LRV) 1, 3, 4
Analog Output Test 1, 2, 2
Auto Zero 1, 2, 4, 4
Auxiliary Output Control 1, 4, 3, 2
Base Time Unit 1, 3, 2, 2, 4
Base Volume Unit 1, 3, 2, 2, 2
Burst Mode Control 1, 4, 3, 6, 3
Burst Mode Options 1, 4, 3, 6, 4
Calibration 1, 2, 4
Calibration Number 1, 3, 6
Coil Frequency 1, 4, 4, 3
Conversion Number 1, 3, 2, 2, 3
Damping 1, 3, 7
D/A Trim 1, 2, 4, 1
Date 1, 4, 5, 5
Descriptor 1, 4, 5, 3
Device ID 1, 4, 5, 6
Digital/Electronics Trim 1, 2, 4, 3
Flow Rate Unit 1, 3, 2, 2, 5
Flowtube Serial Number 1, 4, 5, 7
Flow Units 1, 4, 2
Gross Totalized Value 1, 4, 1
Line Size 1, 3, 5
Loop Test 1, 2, 2
Low Flow Cutoff 1, 4, 4, 1
Lower Range Value 1, 3, 4
Function HART Fast Key
Message 1, 4, 5, 4
Net Totalized Value 1, 4, 2
Number Requested Preams 1, 4, 3, 6, 2
Poll Address 1, 4, 3, 6, 1
Process Variables–PV 1, 1
Pulse Output 1, 1, 5
Pulse Output Loop Test 1, 2, 3
Pulse Scaling 1, 4, 3, 3, 1
Pulse Width 1, 4, 3, 3, 2
PV Percent Range 1, 1, 2
PV Unit 1, 3, 2
Reverse Totalized Value 1, 4, 3
Review 1, 5
Scaled D/A Trim 1, 2, 4, 2
Self Test 1, 2, 1, 2
Sensor–PV 1, 1, 1
Signal Processing 1, 4, 4
Signal Processing–
Percent Limit
1, 4, 4, 6
Signal Processing–Samples 1, 4, 4, 5
Signal Processing–Status 1, 4, 4, 4
Signal Processing–Time Limit 1, 4, 4, 7
Special Units 1, 4, 2, 2
Tag Number 1, 3, 5, 2
Totalize Reset 1, 1, 4, 6
Totalize Start 1, 1, 4, 4
Totalize Stop 1, 1, 4, 5
Upper Range Value 1, 3, 3
Volume Unit 1, 3, 2, 2, 1
Write Protect 1, 4, 5, 9
