Rosemount 8732C - Flange Type; Flange Material

4-17
Transmitter Functions
Flange Type Flange Type enables you to specify the type of flange on the transmitter for
later reference. This variable is preset at the factory but can be changed
if necessary.
• ANSI 150
• ANSI 300
• ANSI 600
• ANSI 900
• PN 10
• PN 16
• PN 25
• PN 40
• PN 64
• Flangeless
• Other
Flange Material Flange Material is a factory-set configuration variable that reflects
the construction of your flowtube.
• Carbon steel
• 304 SST
•316L SST
• Flangeless
• Other
For flowtubes without flanges, this screen can be ignored or used to
indicate the adjacent pipe flange material.
HART Fast Keys
1, 4, 5
LOI
Device Information
HART Fast Keys 1, 4, 5
LOI Device Information
