Rosemount 8732C - LOI Screen Flow Overview

3-5
Local Operator Interface
LOI SCREEN FLOW
DISPLAY
TOTALIZER
DISPLAY SETUP
BASIC SETUP
DETAILED SETUP
TRANSMITTER
TEST
TRANSMITTER
TRIM
DEVICE
INFORMATION
↑ Flow Rate Display
↓ Totalize Display
Display Lock
↑ →Units
Tube Size
Tube Cal. No.
URV, LRV
Damping
↓ End of List
↑ →Lo-Flow Cutoff
Dig Out Config
Special Units
Coil Frequency
Sig Processing
↓ End of List
↑ →Xmtr. Test
Loop Test
Pulse Test
↓ End of List
↑ →4–20 mA Trim
Auto Zero
Gain Trim
↑ →Error Messages
Xmtr. Tag
Xmtr. S/N
Software Rev.
Description
Messages
Flowtube Tag
Flowtube S/N
Liner Material
Electrode Type
Electrode Material
Flange Type
↓ Flange Material
↑ →URV Configure
↓ LRV Configure
↑ →Dig Out Select
Pulse Output
↓ Aux Output
↑ →Sig Processing Control
Sig Processing Samples
Sig Processing Max% Limit
↓ Sig Processing Time Limit
↑ →
↓
