Rosemount 8732C - HART Communicator Menu Tree

Rosemount Model 8732C Integral Mount Magnetic Flowmeter System
A-2
FIGURE A-1. HART Communicator Menu Tree.
NOTE
The Review menu lists all of the information stored in the
Model 8732C. This includes device information,
measuring element, signal condition, output condition,
and software revision.
1 Flow Rate
2 Percent of Range
3 Analog Output
4 TOTALIZER
5 Pulse Output
1 Tag
2 PV UNITS
3 Upper Range Value
4 Lower Range Value
5 Line Size
6 Calibration Number
7 Damping
1 Manufacturer
2 Tag
3 Descriptor
4 Message
5 Date
6 Device ID
7 Flowtube S/N
8 Flowtube Tag
9 Write Protect
– REV NUMBER
– CONSTRUCTION MAT’L
1 DEVICE SETUP
2 PV
3 AO
4 LRV
5 URV
1 PROCESS
VARIABLE
2 DIAGNOSTICS
& SERVICE
3 BASIC SETUP
4 DETAILED
SETUP
5 REVIEW
1 SELF TEST/STATUS
2 Loop Test
3 Pulse Output Test
4 CALIBRATION
1 CHARACTERIZE
METER
2 PV UNITS
3 CONFIGURE
OUTPUTS
4 SIGNAL
PROCESSING
5 DEVICE INFO
1 Line Size
2 Calibration Number
3 Coil Drive Freq.
4 Upper Spec. Limit (view)
5 Lower Spec Limit (view)
6 PV Min Span
On-line Menu
1 View Status
2 Self Test
1 D/A Trim
2 Scaled D/A Trim
3 Electronics Trim
4 Auto Zero Trim
1 ANALOG OUTPUT
2 Aux/Pulse
Output Control
3 PULSE OUTPUT
4 AUX. OUTPUT
5 TOTALIZER
6 HART OUTPUT
1 Pulse Output Scaling
2 Pulse Width
3 Pulse Output Test
1 Poll Address
2 # Preambles
3 Burst Mode Control
4 Burst Option
1 Gross Totalized Value
2 Net Totalized Value
3 Reverse Totalized Value
4 Start Totalizer
5 Stop Totalizer
6 Reset Totalizer
1 User Defined Vol Unit
2 Base Vol Unit
3 Conversion Number
4 Base Time Unit
5 User Defined Flow Unit
1 Upper Range Value
2 Lower Range Value
3 Analog Output
4 Alarm Type
5 Loop Test
1 Flow Rate Units
2 SPECIAL UNITS
1 Flow Rate Units
2 SPECIAL UNITS
1 Base Vol Unit
2 Base Time Unit
3 Conversion Number
4 User Defined Vol Unit
5 User Defined Flow Unit
1 Reverse Flow Enable
2 Zero Flow Enable
1 Gross Totalized Value
2 Net Totalized Value
3 Reverse Totalized Value
4 Start Totalizer
5 Stop Totalizer
6 Reset Totalizer
1 Low Flow Cutoff
2 Damping
3 Coil Drive Freq.
4 Signal Processing Status
5 # of Samples
6 Max % Limit
7 Time Limit
1 Univ. Rev
2 Xmtr Rev
3 Software Rev
1 Fig Type
2 Flange Material
3 Electrode Type
4 Electrode Material
5 Liner Material
