Rosemount Model 8732C Integral Mount Magnetic Flowmeter System
3-4
LOI EXAMPLES
Use the Transmitter Parameter keys shown in Figure 3-1 to change the
parameters. The parameters are set in one of two ways: Table Value
and Select Value.
Table Values
Parameters that are available from a predefined list, such as units.
Select Values
Parameters that consist of a user-created number or character string, such as a
calibration number. Values are entered one character at a time using the data
entry keys.
Table Value
Example
Setting the TUBE SIZE:
1. Access the tube size through basic setup.
2. Press
↑ or ↓ to increment the tube size to the next value.
3. When you reach the desired size, press
E←.
4. Set the loop to manual if necessary, and press
E← again.
After a moment, the LCD will display the new tube size and the
maximum flow rate.
Select Value
Example
Changing the UPPER RANGE VALUE (URV):
1. Access the URV through basic setup.
2. Press
→ to position the cursor.
3. Press
↑ or ↓ to set the number.
4. Repeat steps 2 and 3 until the desired number is displayed.
5. Press
E←.
