Rosemount 8732C - Page 28

Rosemount Model 8732C Integral Mount Magnetic Flowmeter System
2-16
Earth
Ground
8732C-0281F02A
Grounding Rings
FIGURE 2-16. Model 8705
Grounding for Conductive Lined
Pipe with Grounding Rings.
Earth
Ground
Lining
Protector Tab
8732-00281K02A
Lining
Protectors
FIGURE 2-17. Model 8705
Grounding for Non-Conductive
Pipe with Lining Protectors.
8732-0281L02A
Grounding Rings
Earth
Ground
FIGURE 2-18. Model 8705
Grounding for Non-Conductive
Pipe with Grounding Rings.
