Rosemount Model 8732C Integral Mount Magnetic Flowmeter System
2-18
8711-03660A01D
Earth
Ground
Grounding Rings
FIGURE 2-21. Model 8711
Grounding for Conductive Lined
Pipe with Grounding Rings.
8711-03660a01B
Earth
Ground
Grounding Rings
FIGURE 2-22. Model 8711
Grounding for Non-Conductive
Pipe with Grounding Rings.
8711-0368A01A
Earth
Ground
FIGURE 2-23. Model 8711
Grounding for Non-Conductive
Pipe with Grounding Electrodes.
