Rosemount Model 8732C Integral Mount Magnetic Flowmeter System
7-10
(1) W1 is shipped with a 5 psi housing relief valve.
(2) Teflon (T) liner only. W1 option required. Only Stainless Steel Tri-Clamp Adapters available. Available with
Stainless Steel, Hastelloy, and Platinum – 10% Iridium type electrodes.
Code Optional Grounding Rings and Lining Protection
G
L
Grounding Ring
Lining Protectors
Code Grounding Rings, Lining Protector Wetted Material
1
2
3
4
316L SST
Hastelloy C-276
(Available in ½-through 12-inch (15 - 300mm) sizes only.)
Titanium (Available in ½-through 12-inch (15 - 300mm) sizes only.)
Tantalum (Available in ½- through 8-inch (15 - 200 mm) sizes only.) (Not available with option code L.)
Code Options
W1
H1
B1
B3
KD
Q4
Q5
Q8
Q9
A3
Standard sealed, welded housing without sealed electrode compartments
(1)
Not available with field-removable electrodes (Option Code R)
Flowtube with Model 8701 lay length (Available for ½ through 16-inch (15–400 mm) line sizes)
(For ½ through 4-inch (15–100 mm) sizes, the flowtube is shipped with a spool piece)
Integral Mount with Model 8712C Transmitter
Integral Mount with Model 8732C Transmitter
KEMA/CENELEC Approval
Calibration Data Sheet
Hydrostatic Test Certificate
Material Traceability Certificate per DIN 3.1B
Material Traceability Certificate (Electrodes only) per DIN 3.1B
Sanitary 3-A for ANSI 150 to Tri-Clamp (½- to 3-inches (15-80 mm) sizes only)
(2)
Typical Model Number: 8705 T S A 040 C1 G 1
}
Grounding rings and lining protectors cannot be used together.
Both options provide the same fluid grounding function.
Lining protectors available with PTFE liners only.
To Next Page
