8-5
Model 8711 Specifications and Reference Data
ORDERING INFORMATION
Model Product Description
8711 Magnetic Flowmeter Flowtube (Flangeless Construction)
Code Lining Material
T ETFE Tefzel
Code Electrode Material
S
H
T
P
N
316L SST
Hastelloy C-276
Tantalum
Platinum – 10% Iridium
Titanium
Code Electrode Construction
A
E
Standard Measurement Electrodes (no grounding electrode)
Measurement Electrodes and Grounding Electrode
Code Line Size, Inches (mm)
15F
30F
005
010
015
020
030
040
060
080
0.15 (4)
0.30 (8)
0.5 (15)
1.0 (25)
1.5 (40)
2.0 (50)
3.0 (80)
4.0 (100)
6.0 (150)
8.0 (200)
Code Transmitter Mounting Configuration
R
S
U
Remote (2-inch Pipe or Surface Mount)
Integral with Model 8712C Transmitter
Integral with Model 8732C Transmitter
Code Mounting Kit
1
2
3
4
ANSI Class 150
DIN PN 10/16 (8 inch (200mm) has a PN 10 Mounting Kit Only.)
ANSI Class 300
DIN PN 25/40 (8 inch (200mm) has a PN 25 Mounting Kit Only.)
Code Option
E5
G1
G2
G3
G4
CD
Q4
Q8
Q9
Factory Mutual (FM) Explosion Proof Approvals
Grounding Rings, 316L SST
Grounding Rings,
Hastelloy C-276
Grounding Rings, Titanium
Grounding Rings, Tantalum
KEMA/CENELEC Flameproof Approvals
Calibration Data Sheet
Material Traceability Certificate per DIN 3.1B
Material Traceability Certificate (Electrodes only) per DIN 3.1B
Typical Model Number: 8711 T S A 040 R 1 G1
