Rosemount 8800D Series User Manual

Reference Manual
00809-0100-4004, Rev BA
August 2010
A-3
Rosemount 8800D
Process Temperature Limits
Standard
–40 to 450 °F (–40 to 232 °C)
Extended
–330 to 800 °F (–200 to 427 °C)
MultiVariable (MTA option)
–50 to 800 °F (–40 to 427 °C)
• Use above 450 °F (232 °C) requires Extended Sensor
Output Signals
4–20 mA Digital HART Signal
Superimposed on 4–20 mA signal
Optional Scalable Pulse Output
0 to 10000 Hz; transistor switch closure with adjustable scaling via HART communications;
capable of switching up to 30 Vdc, 120 mA maximum
Digital F
OUNDATION fieldbus signal
Completely digital output with F
OUNDATION fieldbus communication (ITK 5.2 compliant).
Analog Output Adjustment
Engineering units and lower and upper range values are user-selected. Output is automatically
scaled to provide 4 mA at the selected lower range value, 20 mA at the selected upper range
value. No frequency input is required to adjust the range values.
Scalable Frequency Adjustment
The scalable pulse output can be set to a specific velocity, volume, or mass (i.e. 1 pulse = 1 lb).
The scalable pulse output can also be scaled to a specific rate of volume, mass, or velocity (i.e.
100 Hz = 500 lb/hr).
Ambient Temperature Limits
Operating
–58 to 185 °F (–50 to 85 °C)
–4 to 185 °F (–20 to 85 °C) for flowmeters with local indicator
Storage
–58 to 250 °F (–50 to 121 °C)
–50 to 185 °F (–46 to 85 °C) for flowmeters with local indicator
Pressure Limits
Flange Style Meter
Rated for ASME B16.5 (ANSI) Class 150, 300, 600, 900, and 1500, DIN PN 10, 16, 25, 40,
64, 100, and 160, and JIS 10K, 20K, and 40K
Reducer Style Meter
Rated for ASME B16.5 (ANSI) Class 150, 300, 600, and 900, DIN PN 10, 16, 25, 40, 64, 100,
and 160.
Dual Sensor Style Meter
Rated for ASME B16.5 (ANSI) Class 150, 300, 600, 900, and 1500, DIN PN 10, 16, 25, 40,
64, 100, and 160, and JIS 10K, 20K, and 40K
Wafer Style Meter
Rated for ASME B16.5 (ANSI) Class 150, 300, and 600, DIN PN 10, 16, 25, 40, 64, and 100,
and JIS 10K, 20K, and 40K
NOTE:
All Wafer Style Meters are pressure rated and labeled at 1500 PSI / 10.34
MPa at 100 °F / 38 °C regardless of Alignment Ring Size code ordered.

Rosemount 8800D Series Specifications

General

Type	Vortex Flow Meter
Measurement Principle	Vortex Shedding
Operating Temperature	-40 to 185°F (-40 to 85°C)
Storage Temperature	-40 to 185°F (-40 to 85°C)
Communication Protocols	FOUNDATION Fieldbus
Material	316 stainless steel
Fluid Type	Liquid, Gas, Steam
Line Size	1/2 to 8 inches (15 to 200 mm)
Approvals	ATEX, IECEx, CSA, FM
Output Signal	4-20 mA
Process Connection	Flanged, Wafer, Threaded
Electrical Connection	M20
Protection Rating	IP66
Mounting Style	Wafer, Flanged
