Rosemount 8800D Series User Manual

Reference Manual
00809-0100-4004, Rev BA
August 2010
3-5
Rosemount 8800D
Mass Flow Units
NOTE
If you select a Mass Units option, you must enter process density in your
configuration. See the Density/Density Ratio section on page 3-9.
Velocity Flow
Allows the user to view the current velocity flow value and units. Also allows
the user to configure the velocity flow units.
Velocity Flow
Displays the current velocity flow value and units.
Velocity Units
Allows the user to select the velocity units from the available list.
Velocity Measured Base
Velocity Measured Base will determine if the velocity measurement is based
on the mating pipe ID or the meter body ID. This is important for Reducer
™
Vortex Applications.
Totalizer
Totalizer — Totalizer tallies the total amount of liquid or gas that has passed
through the flowmeter since the totalizer was last reset.
It enables you to change the settings of the totalizer.
Total
Total — Provides the output reading of the totalizer. Its value is the amount of
liquid or gas that has passed through the flowmeter since the totalizer was
last reset
lb/s STon/min
lb/min STon/h
lb/h STon/d
lb/d MetTon/min
kg/s MetTon/h
kg/min MetTon/d
kg/h g/s
kg/d g/min
g/h
Field Comm. 1, 1, 4, 3
Field Comm. 1, 1, 4, 3, 1
Field Comm. 1, 1, 4, 3, 2
ft/s
m/s
Field Comm. 1, 1, 4, 3, 3
Field Comm. 1, 1, 4, 4
Field Comm. 1, 1, 4, 4, 1

Rosemount 8800D Series Specifications

General

Type	Vortex Flow Meter
Measurement Principle	Vortex Shedding
Operating Temperature	-40 to 185°F (-40 to 85°C)
Storage Temperature	-40 to 185°F (-40 to 85°C)
Communication Protocols	FOUNDATION Fieldbus
Material	316 stainless steel
Fluid Type	Liquid, Gas, Steam
Line Size	1/2 to 8 inches (15 to 200 mm)
Approvals	ATEX, IECEx, CSA, FM
Output Signal	4-20 mA
Process Connection	Flanged, Wafer, Threaded
Electrical Connection	M20
Protection Rating	IP66
Mounting Style	Wafer, Flanged
