Reference Manual
00809-0100-4004, Rev BA
August 2010
Rosemount 8800D
3-6
Start
Start — Starts the totalizer counting from its current value.
Stop
Stop — Interrupts the totalizer count until it is restarted again. This feature is
often used during pipe cleaning or other maintenance operations.
Reset
Reset — Returns the totalizer value to zero. If the totalizer was running, it will
continue to run starting at zero.
Totalizer Config
Totalizer Config — Used to configure the flow parameter (volume, mass,
velocity) that will be totalled.
NOTE
The totalizer value is saved in the non-volatile memory of the electronics
every three seconds. Should power to the transmitter be interrupted, the
totalizer value will start at the last saved value when the power is re-applied.
NOTE
Changes that affect the density, density ratio, or compensated K-Factor will
affect the totalizer value being calculated. These changes will not cause the
existing totalizer value to be recalculated.
Pulse Frequency
Allows users to view the pulse output frequency value. To configure the pulse
output, refer to the section on pulse output found on page 4-9.
Vortex Frequency
Allows users to view the shedding frequency directly off of the sensor.
Electronics Temperature
Allows users to view the electronics temperature value and units. Also allows
the user to configure the units for the electronics temperature.
Field Comm. 1, 1, 4, 4, 2
Field Comm. 1, 1, 4, 4, 3
Field Comm. 1, 1, 4, 4, 4
Field Comm. 1, 1, 4, 4, 5
Field Comm. 1, 1, 4, 5
Field Comm. 1, 1, 4, 6
Field Comm. 1, 1, 4, 7
