Rosemount 8800D Series User Manual

Reference Manual
00809-0100-4004, Rev BA
August 2010
3-7
Rosemount 8800D
Electronics Temperature
Displays the current electronics temperature value and units.
Electronics Temperature Unit
Allows the user to select the units for electronics temperature from the
available list.
Calculated Process Density
Allows users to view the calculated process density value when the vortex is
configured for temperature compensated steam applications. Also allows the
user to configure the calculated density units.
Process Density
Displays the current calculated process density value.
Density Units
Allows the user to configure the units for the calculated process density from
the available list.
Process Temperature
Allows users to view the process temperature value when the vortex
transmitter has the temperature sensor option. Also allows the user to
configure the process temperature units.
Process Temperature
Displays the current process temperature value.
Field Comm. 1, 1, 4, 7, 1
Field Comm. 1, 1, 4, 7, 2
deg C
deg F
Field Comm. 1, 1, 4, 8
Field Comm. 1, 1, 4, 8, 1
Field Comm. 1, 1, 4, 8, 2
g/Cucm (cm
3
)
g/L
kg/Cum (m
3
)
lb/Cuft (ft
3
)
lb/Cuin (in
3
)
Field Comm. 1, 1, 4, 9
Field Comm. 1, 1, 4, 9, 1

Rosemount 8800D Series Specifications

General

Type	Vortex Flow Meter
Measurement Principle	Vortex Shedding
Operating Temperature	-40 to 185°F (-40 to 85°C)
Storage Temperature	-40 to 185°F (-40 to 85°C)
Communication Protocols	FOUNDATION Fieldbus
Material	316 stainless steel
Fluid Type	Liquid, Gas, Steam
Line Size	1/2 to 8 inches (15 to 200 mm)
Approvals	ATEX, IECEx, CSA, FM
Output Signal	4-20 mA
Process Connection	Flanged, Wafer, Threaded
Electrical Connection	M20
Protection Rating	IP66
Mounting Style	Wafer, Flanged
