Rosemount 8800D Series User Manual

Reference Manual
00809-0100-4004, Rev BA
August 2010
Rosemount 8800D
3-17
Table 3-3. Fast Keys for Rosemount 8800D Device Revision 2 DD Revision 3
Function Fast Key Function Fast Key
Alarm Direction 1, 3, 1, 3, 2 Percent of Range 3, 4, 3, 2
Analog Output 3, 4, 3, 1 Polling Address 2, 2, 7, 1
Analog Trim 3, 4, 3, 6 Primary Variable Damping 2, 1, 4, 1
Base Time Unit 2, 2, 2, 3, 2 Primary Variable 2, 2, 2, 1, 1
Base Volume Unit 2, 2, 2, 3, 1 Process Density Units 2, 2, 2, 2, 7
Burst Mode 2, 2, 7, 2 Process Fluid Type 2, 2, 1, 1, 2
Burst Option 2, 2, 7, 3 Process Temp Units 2, 2, 2, 2, 5
Burst Slot 0 2, 2, 7, 4, 1 Process Variables 3, 2, 1
Burst Slot 1 2, 2, 7, 4, 2 Pulse Output 3, 2, 4, 4
Burst Slot 2 2, 2, 7, 4, 3 Pulse Output Test 3, 5, 3, 4
Burst Slot 3 2, 2, 7, 4, 4 Recall Factory Calibration 3, 4, 3, 8
Burst Variable Mapping 2, 2, 7, 4, 5 Reference K-Factor 2, 2, 1, 2, 1
Compensated K-Factor 2, 2, 1, 2, 2 Reset Transmitter 3, 4, 1, 2
Conversion Number 2, 2, 2, 3, 4 Restore Default Filters 2, 1, 4, 6
Date 2, 2, 8, 2, 1 Revision Numbers 3, 1, 1, 9
Descriptor 2, 2, 8, 2, 2 Scaled Analog Trim 3, 4, 3, 7
Density Ratio 2, 2, 3, 3, 2 2nd Variable 2, 2, 2, 1, 2
Device ID 3, 1, 1, 5 Self Test 3, 4, 1, 1
Display 2, 1, 1, 2 Set Variable Mapping 2, 2, 2, 1, 5
Electronics Temp 3, 2, 5, 4 Shedding Frequency 3, 2, 4, 2
Electronics Temp Units 2, 2, 2, 2, 6 Signal Strength 3, 2, 5, 2
Final Assembly Number 2, 2, 8, 1, 4 Special Flow Unit 2, 2, 2, 3, 5
Fixed Process Density 2, 2, 1, 1, 5 Special Volume Unit 2, 2, 2, 3, 3
Fixed Process Temperature 2, 2, 1, 1, 4 Standard/Normal Units 2, 2, 3
Flange Type 2, 2, 1, 4, 2 Status 1, 1, 1
Flow Simulation 3, 5, 1 Tag 2, 2, 8, 1, 1
4th Variable 2, 2, 2, 1, 4 3rd Variable 2, 2, 2, 1, 3
Installation Effects 2, 2, 1, 1, 7 Total 1, 3, 6, 1
Lower Range Value 2, 2, 4, 1, 4 Totalizer Configuration 1, 3, 6, 3
Lower Sensor Limit 2, 2, 4, 1, 5, 2 Totalizer Control 1, 3, 6, 2
Loop Test 3, 5, 2, 6 Transmitter Mode 2, 2, 1, 1, 1
Low Flow Cutoff 2, 1, 4, 3 Trigger Level 2, 1, 4, 5
Low-pass Corner Frequency 2, 1, 4, 4 Upper Range Value 2, 2, 4, 1, 3
Manufacturer 3, 1, 1, 2 Upper Sensor Limit 2, 2, 4, 1, 5, 1
Mass Flow 3, 2, 3, 6 Velocity Flow 3, 2, 3, 4
Mass Flow Units 2, 2, 2, 2, 4 Velocity Flow Units 2, 2, 2, 2, 2
Mating Pipe ID (Inside Diameter) 2, 2, 1, 1, 6 Velocity Measurement Base 2, 2, 2, 2, 3
Message 2, 2, 8, 2, 3 Volume Flow 3, 2, 3, 2
Meter Body Number 2, 2, 1, 4, 5 Volume Flow Units 2, 2, 2, 2, 1
Minimum Span 2, 2, 4, 1, 6 Wetted Material 2, 2, 1, 4, 1
Optimize DSP 2, 1, 1, 3 Write Protect 3, 1, 3, 1

Rosemount 8800D Series Specifications

General

Type	Vortex Flow Meter
Measurement Principle	Vortex Shedding
Operating Temperature	-40 to 185°F (-40 to 85°C)
Storage Temperature	-40 to 185°F (-40 to 85°C)
Communication Protocols	FOUNDATION Fieldbus
Material	316 stainless steel
Fluid Type	Liquid, Gas, Steam
Line Size	1/2 to 8 inches (15 to 200 mm)
Approvals	ATEX, IECEx, CSA, FM
Output Signal	4-20 mA
Process Connection	Flanged, Wafer, Threaded
Electrical Connection	M20
Protection Rating	IP66
Mounting Style	Wafer, Flanged
