Reference Manual
00809-0100-4004, Rev BA
August 2010
Rosemount 8800D
3-16
Table 3-2. Field Communicator Fast Key Sequences for the Rosemount 8800D
*Figure 3-1 and Table 3-2 are for Device Revision 1 and Device Revision 2 DD Revision 1 Rosemount 8800D
Menu Tree and Fast Key codes
Function Fast Keys
Alarm Jumper 1, 4, 2, 1, 3
Analog Output 1, 4, 2, 1
Auto Adjust Filter 1, 4, 3, 1, 4
Base Time Unit 1, 1, 4, 1, 3, 2
Base Volume Unit 1, 1, 4, 1, 3, 1
Burst Mode 1, 4, 2, 3, 4
Burst Option 1, 4, 2, 3, 5
Burst Variable 1 1, 4, 2, 3, 6, 1
Burst Variable 2 1, 4, 2, 3, 6, 2
Burst Variable 3 1, 4, 2, 3, 6, 3
Burst Variable 4 1, 4, 2, 3, 6, 4
Burst Xmtr Variables 1, 4, 2, 3, 6
Conversion Number 1, 1, 4, 1, 3, 4
D/A Trim 1, 2, 5
Date 1, 4, 4, 5
Descriptor 1, 4, 4, 3
Density Ratio 1, 3, 2, 4, 1, 1
Device ID 1, 4, 4, 7, 6
Electronics Temp 1, 1, 4, 7, 1
Electronics Temp Units 1, 1, 4, 7, 2
Filter Restore 1, 4, 3, 3
Final Assembly Number 1, 4, 4, 7, 5
Fixed Process Density 1, 3, 2, 4, 2
Fixed Process Temperature 1, 3, 2, 3
Flange Type 1, 3, 4
Flow Simulation 1, 2, 4
Installation Effects 1, 4, 1, 6
K-Factor (reference) 1, 3, 3
Local Display 1, 4, 2, 4
Loop Test 1, 2, 2
Low Flow Cutoff 1, 4, 3, 2, 3
Low Pass Filter 1, 4, 3, 2, 4
LRV 1, 3, 8, 2
LSL 1, 3, 8, 5
Manufacturer 1, 4, 4, 1
Mass Flow 1, 1, 4, 2, 1
Mass Flow Units 1, 1, 4, 2, 2
Mating Pipe ID (Inside
Diameter)
1, 3, 5
Message 1, 4, 4, 4
Meter Body Number 1, 4, 1, 5
Minimum Span 1, 3, 8, 3
Num Req Preams 1, 4, 2, 3, 2
Function Fast Keys
Poll Address 1, 4, 2, 3, 1
Process Fluid Type 1, 3, 2, 2
Process Variables 1, 1
Pulse Output 1, 4, 2, 2, 1
Pulse Output Test 1, 4, 2, 2, 2
PV Damping 1, 3, 9
PV Mapping 1, 3, 6, 1
PV Percent Range 1, 1, 2
QV Mapping 1, 3, 6, 4
Range Values 1, 3, 8
Review 1, 5
Revision Numbers 1, 4, 4, 7
Scaled D/A Trim 1, 2, 6
Self Test 1, 2, 1, 5
Signal to Trigger Ratio 1, 4, 3, 2, 2
STD/Nor Flow Units 1, 1, 4, 1, 2
Special Units 1, 1, 4, 1, 3
Status 1, 2, 1, 1
SV Mapping 1, 3, 6, 2
Tag 1, 3, 1
Total 1, 1, 4, 4, 1
Totalizer Control 1, 1, 4, 4
Transmitter Mode 1, 3, 2, 1
TV Mapping 1, 3, 6, 3
Trigger Level 1, 4, 3, 2, 5
URV 1, 3, 8, 1
User Defined Units 1, 1, 4, 1, 3, 3
USL 1, 3, 8, 4
Shedding Frequency 1, 1, 4, 6
Variable Mapping 1, 3, 6
Velocity Flow 1, 1, 4, 3
Velocity Flow Base 1, 1, 4, 3, 3
Volumetric Flow 1, 1, 4, 1
Wetted Material 1, 4, 1, 4
Write Protect 1, 4, 4, 6
