• N2 - determines if the Chime will sound when a valid PIN
code or Prox card is applied to the controller.
Enter “1” to enable this feature
Enter “0” to disable this feature
4. If the 2-digit Chime Alert settings are entered correctly, the
Chime Alert settings will be updated and the controller will
return to Programming Mode.
• The Mode LED will turn orange
If the 2-digit Chime Alert settings are entered incorrectly,
the Chime Alert settings will NOT be updated. You will hear
a long beep and the controller will exit Programming Mode
and return to Normal Mode.
• The Mode LED will turn green
4.29 Setting up the Real Time Clock (RTC) - Year
1. Enter Programming Mode
• Mode LED will turn orange
2. Press ”51” to enter Menu 51
• The Mode LED will turn red
3. Enter the 2-digit year.
The two digits represent the last two digits of the Year. By
default the first two digits are 20.
For example if you enter “12” the year
would be 2012.
4. If the 2-digit year is entered correctly, the year will be
updated and the controller will return to Programming
Mode.
• The Mode LED will turn orange
If the 2-digit date is entered incorrectly, the year will NOT
be updated. You will hear a long beep and the controller
will exit Programming Mode and return to Normal Mode.
• The Mode LED will turn green
Mode
Door
Green
Mode
Door
Oran
e
5 1
Mode
Door
Red
Mode Door
Green
Y Y
To Next Page
