Installation
AC-115 Hardware Installation and User's Guide
Page 12
2.2 Power Wiring
0
8
5
21
46
3
9
7
#
MODE
DOOR
POWER SUPPLY
FROM
TRANSFORMER
16.5V AC (1.5A, 40VA)
(+)
(-)
12V DC LEAD ACID
BATTERY
UP TO 7 AH
(Not for UL
Installations)
(+)
(-)
Figure 2: Power Wiring
2.3 Typical Lock and Option Wiring
0
8
5
21
46
3
9
7
#
MODE
DOOR
REX
GND
+12VDC
A
UX Out
Monitor
+ BAT
GND
+12VDC
Figure 3: Typical Lock and Option Wiring
Note:
For Fail Secure application, the listed panic hardware shall be
used to allow emergency exit from the protected area.
