Introduction
Page 7 AC-115 Hardware Installation and User's Guide
• Programmable Lock Strike & Auxiliary Relay release time.
• Built-in Lock Strike suppressor diode.
• Comes with mounting template for easier installation.
• Built-in Reader Power Supply
• Built-in Lock Strike Power Supply
1.2 Technical Specifications
Electrical Characteristics
Main Unit
Operating Voltage AC Input - Class 2 transformer
model PTC1640U, 16.5Vac, 40VA
Maximum Input Current (Not including attached devices)
Standby: 65mA
Maximum: 120mA
Battery Charger (not
tested by UL)
12V DC Lead Acid Battery
Up to 7AH recommended
Outputs
Lock Strike Relay Output
5A Relay
Max Load: 1.2A
Lock Strike Power Supply
12V DC constant voltage
1.2 A current limit
Auxiliary Relay Output 1A Relay Closed to Ground
Max Load: 1A (AUX load & Lock
Strike not to exceed 1.2A)
Reader Power Supply Voltage: 11~12V DC
Max Current: 300mA (for a
combination of both In and Out
Readers)
Inputs
Release to Exit (REX) N.O. Dry Contact
Door Monitor N.C. Dry Contact
