Rosslare AC-115 User Manual

Programming Instructions
AC-115 Hardware Installation and User's Guide Page 42
Mode
Door
Oran
g
e
2. Press ”45” to enter Menu 45
• The Mode LED will turn red
3. Enter the 2-digit Rex Event settings.
• N1 - first digit determines if the lock strike relay is
activated when the REX button is pushed.
Enter “1” to enable this feature
Enter “0” to disable this feature
• N2 - determines if the auxiliary relay is activated when
the REX button is pushed.
Enter “1” to enable this feature
Enter “0” to disable this feature
4. If the 2-digit REX Event settings are entered correctly, the
REX Event settings will be updated and the controller will
return to Programming Mode.
• The Mode LED will turn orange
If the 2-digit REX Event settings are entered incorrectly, the
REX Event settings will not be updated. You will hear a long
beep and the controller will exit Programming Mode and
return to Normal Mode.
• The Mode LED will turn green
4.28 Setting up the Chime Alert Event Action
1. Enter Programming Mode
• Mode LED will turn orange
2. Press ”46” to enter Menu 46
• The Mode LED will turn red
3. Enter the 2-digit Chime Alert settings.
• N1 - first digit determines if the Chime will sound when the
Door Monitor input is activated.
Enter “1” to enable this feature
Enter “0” to disable this feature
4 5
Mode Door
Red
N1 N2
Mode
Door
Green
Mode
Door
Oran
g
e
4 6
Mode Door
Red
N1 N2
