4.23 Setting up the Door Ajar Event Actions
1. Enter Programming Mode
• Mode LED will turn orange
2. Press ”41” to enter Menu 41
• The Mode LED will turn red
3. Enter the 2-digit Door Ajar Event settings.
• N1 - determines if the auxiliary relay is activated when a
Door Ajar Event occurs.
Enter “1” to enable this feature
Enter “0” to disable this feature
• N2 - determines if the internal siren is activated when a
Door Ajar Event occurs.
Enter “1” to enable this feature
Enter “0” to disable this feature
4. If the 2-digit Door Ajar Event settings are entered correctly,
the Door Ajar Event settings will be updated and the
controller will return to Programming Mode.
• The Mode LED will turn orange
If the 2-digit Door Ajar Event settings are entered
incorrectly, the Door Ajar Event settings will NOT be
updated. You will hear a long beep and the controller will
exit Programming Mode and return to Normal Mode.
• The Mode LED will turn green
4.24 Setting up the Forced Door Event Actions
1. Enter Programming Mode
• Mode LED will turn orange
2. Press ”42” to enter Menu 42
• The Mode LED will turn red
3. Enter the 2-digit Forced Door Event settings.
• N1 - determines if the auxiliary relay is activated when a
Forced Door Event occurs.
Enter “1” to enable this feature
Enter “0” to disable this feature
Mode
Door
Oran
g
e
4 1
Mode
Door
Red
N1 N2
Mode
Door
Green
Mode
Door
Oran
g
e
4 2
Mode
Door
Red
N1 N2
