Programming Instructions
Page 35 AC-115 Hardware Installation and User's Guide
0 N2 N3 N4
Mode
Door
Oran
e
If the 4-digit settings code is entered incorrectly, the
settings will NOT be updated. You will hear a long beep
and the controller will exit Programming Mode and return
to Normal Mode.
• The Mode LED will turn green
4.18 Setting up the Door Ajar Time
1. Enter Programming Mode
• Mode LED will turn orange
2. Press ”32” to enter Menu 32
• The Mode LED will turn red
3. Create and enter the 4-digit settings
code.
• 0 - First digit is always “0”
• N2 - Ajar Time must be between 0 to 9 minutes.
• N3 and N4 - Ajar Time must be between 00 to 59
seconds.
4. If the 4-digit settings code is entered correctly, the settings
will be updated and the controller will return to
Programming Mode.
• The Mode LED will turn orange
If the 4-digit settings code is entered incorrectly, the
settings will NOT be updated. You will hear a long beep
and the controller will exit Programming Mode and return
to Normal Mode.
• The Mode LED will turn green
Note:
A Door Ajar time of 0:00 will disable the Door Ajar Event.
4.19 Setting up the Forced Door Time
1. Enter Programming Mode
• Mode LED will turn orange
Mode
Door
Green
Mode
Door
Oran
e
3 2
Mode Door
Mode
Door
Green
Mode
Door
Oran
e
To Next Page
