Programming Instructions
AC-115 Hardware Installation and User's Guide
Page 26
Mode
Door
Red
Green
? ? ? ?
? ? ? ?
Mode
Door
Red
Green
Mode
Door
Red
Orange
3. Enter the 4-Digit Employee Slot Code you
wish to add.
The Door LED will flash green, indicating that controller is
ready to learn the employees Proximity
Card or PIN Code.
4. Present a Proximity Card to one of the attached readers or
enter a 1 to 6-digit PIN Code. If your Programming Code is
less than 6-digits long, don’t forget to press the “#” key to
confirm your entry after entering your Programming Code.
If the Proximity Card or PIN is valid, the Mode LED will stop
flashing. The controller is ready for you to add the next 4-
digit Employee Slot Code or to press the
“#” key to move to the next slot number.
If you do not wish to continue enrolling codes, press the “#”
key for 2 seconds and the controller will return to Normal
Mode.
4.7 Lock Strike Relay and Auxiliary Relay Code
Assignment
1. Enter Programming Mode
• Mode LED will turn orange
2. Press ”12” to enter Menu 12
• The Mode LED will turn red
• The Door LED will turn green
3. Enter the 4-Digit Employee Slot Code that
you wish to assign a code to.
The Door LED will turn orange
4. Enter your 2-digit assignment code.
• N1- determines if the Lock Strike Relay is activated or not.
“1” = Lock Strike Activated
“0” = Lock Strike Not Activated
• N2 - Second digit determines if the Auxiliary Relay is
activated or not.
“1” = Auxiliary Relay Activated
“0” = Auxiliary Relay Not Activated
Mode
Door
Oran
e
1 2
Mode
Door
Red
Green
N1 N2
To Next Page
