Installation
AC-115 Hardware Installation and User's Guide
Page 10
2.1 Mounting the Controller
1. Before starting, select the location to mount the AC-115
controller. The controller should be installed indoors and
within the premises to be secured. It is recommended that
the controller be installed where it cannot be seen for
increased security, but still close enough to the door so that
the controller’s annunciator (Door Bell, Chime & Siren) can
be heard. When selecting a location, take into
consideration how the controller will be attached to a PC
for easier programming and system maintenance.
2. Find the mounting template label that is provided in your
AC-115 packaging, and place it at the location that you
wish to install the controller. The template is designed to
assist you through the mounting procedure, showing you
where you drill holes in the wall to pass the wiring through
and where the wall must be drilled to insert the controllers
mounting screws.
3. (Skip this step when attaching to a US Gang Box)
Drill a hole for cables as indicated on the wiring template.
Two hole sizes are shown to allow for the amount of cables
needed, depending on installation requirements such as
connecting to a PC or adding a backup battery. Drill two
screw holes for mounting the AC-115 to the wall.
4. Remove the case screw from the controller (see diagram
below to locate the case screw) and remove the front
case from the controller.
5. Mount the controller to the wall using the two screws
provided in the Installation Kit or use the screws provided
with your US Gang Box when mounting to a US Gang Box.
