Features and Concepts
AC-115 Hardware Installation and User's Guide
Page 16
Mode
Door
Oran
e
3.2 Modes of Operation
The AC-115 has three modes of operation: Normal, Bypass, and
Secure Mode. The three modes provide different levels of
security.
Normal Mode
• The Mode LED is green
In Normal Mode, both the In Reader (the reader that is
installed outside the premises) and the Out Reader (the reader
that is installed inside the premises) are functioning. The
controller’s programming keypad and the REX button are also
functioning.
When a valid code is entered at the In Reader, the controller
will first check if the employee is attempting entry during a
permitted time zone before activating the Lock Strike Output
and/or the Auxiliary Output. When a valid code is entered at
the Out Reader or the programming keypad, the Lock Strike
Output and/or the Auxiliary Output will open without checking
time zones.
If the Employee Code is Code Assigned to the Lock Strike
Output, the Lock Strike Output will activate, and remain active
until the Lock Strike Release Time has passed or the door
monitor detects that the door has been opened.
If the Employee Code is Code Assigned to the Auxiliary Output,
the Auxiliary Output will activate, and remain active until the
Auxiliary Release Time has passed or toggle if the Auxiliary
Release Time is set to zero.
Bypass Mode
In Bypass Mode, if the Lock Strike Output is set to Normally
Closed, the Lock Strike Output will constantly
be active and the Mode LED will be orange
and the Door LED will be green.
• The Mode LED is orange and the Door LED is green
If the Lock Strike Output is set to Normally Open, pressing the
REX or the bell button, entering a Lock Strike, Auxiliary, or Valid
Code can be used to activate the Lock Strike Output and/or
Mode
Door
Green
