4.5 Deleting all Employee Codes
1. Enter Programming Mode
• Mode LED will turn orange
2. Press ”10” to enter Menu 10
• The Mode LED will turn red
• The Door LED will flash red
3. Enter the Programming Code for
confirmation.
If your Programming Code is less than 6-
digits long, do not forget to press the “#” key to confirm
your entry after entering your Programming Code.
4. If the Programming Code is entered correctly, all Employee
Codes will be deleted. The controller will exit Programming
Mode and return to Normal Mode.
• You will hear a short beep
• The Mode LED will turn green
• The Door LED will stop flashing
If the Programming Code is entered incorrectly, all
Employee Codes will NOT be deleted. The controller will exit
Programming Mode and return to Normal Mode.
• You will hear a long beep
• The Mode LED will turn green
• The Door LED will stop flashing
4.6 Adding an Employee Code
1. Enter Programming Mode
• Mode LED will turn orange
2. Press ”11” to enter Menu 11
• The Mode LED will turn red
• The Door LED will turn green
Mode Door
Oran
g
e
1 0
Mode
Door
Red
Red
Mode
Door
Green
Mode
Door
Green
Mode
Door
Oran
g
e
1 1
Mode
Door
Red
Green
