AS-B01 Software Overview and LEDs
20 CP-R25 Hardware and AS-B01 Software Manual
Event Swipe Card Reader
LED
Fingerprint
Reader LED
Buzzer Fingerprint
Directional
Indication LED
Fingerprint Scanning
Waiting
for
fingerprint
Off Green flashes Off Rolling LEDs in
circular mode to
indicate finger
swipe
Read
fingerprint
success
Off Green on for 3
sec
3 high-tone
beeps
Rolling LEDs in
circular mode to
indicate finger
swipe
Read
fingerprint
fail
Off Red on for 3
sec
Long buzz Turning all LEDs
on, and then
according to
status, leaving all
on or going back
to circular mode
Read finger timeout – When no finger is passed over the scanner for 30
seconds, the CP-R25 Desktop Programmer goes back to Standby mode of
swipe LEDs.
