Programming Cards and Tags
24 CP-R25 Hardware and AS-B01 Software Manual
Refer to the specific reader’s installation manual for a detailed explanation of
the various options.
5.2.1 Sector Reader Configuration Cards
A Sector Reader Configuration card allows you to create a configuration card,
which is used to configure the various sector readers such as the AY-W6260,
AY-W6360, AY-Q6260, and AY-Q6360 units.
To prepare a Sector Reader Configuration card:
1. Select the Sector Reader tab.
2. Select the applicable
Operation Mode , either Sector or Card Serial
Number (CSN).
3. From the
Operation Type dropdown menu, select Program
Configuration Card.
4. In
Card Type , select either Mifare
®
1 K or Mifare
®
4 K.
5. From the
Transmit Format dropdown menu, select the applicable
transmission format.
6. For Sector operation mode, select values for the Sector Number, Block
Number, and Byte Number fields in
ID Location.
7. Ensure that Operations is set to Program Card.
8. Define the
Led and Buzzer Control behavior by selecting or clearing the
Enable Led and Enable Buzzer checkboxes.
9. For readers with a keypad:
a. Select the Keypad checkbox.
Additional keypad options appear.
b. In the Backlight options dropdown menu, select the backlight
behavior.
c. From the Transmit Format dropdown menu, set the keypads’
transmission format.
10. For Sector mode, enter the KeyA to be used by the reader as the unique
KeyA for the organization or site in both the Reader KeyA and the
Confirm Reader KeyA fields.
The KeyA number is hidden by "*" characters, so write down the new key
and keep it in a safe place to avoid exposing this secret key to unauthorized
personnel. The KeyA value is entered as a 12 hexadecimal digit. The default
KeyA is FFFFFFFFFFFF.
11. Place a blank Mifare
®
card or a card previously configured as a
Configuration card on the CP-R25 Desktop Programmer antenna area.
12. Click Start to begin programming the Mifare
®
card.
On completion, a message appears in the Message Log area to verify that
the programming succeeded.
