Additional Programmer Utilities
36 CP-R25 Hardware and AS-B01 Software Manual
Figure 19: Change User Card KeyA and Erase Data – All Sectors
The KeyA fields are displayed.
6. In
KeyA
:
a. Enter the KeyA to be used by the reader as the unique KeyA for the
organization or site in both the Reader KeyA and the Confirm
Reader KeyA fields.
b. Enter the current KeyA of the card being programmed.
• The KeyA number is hidden by "*" characters, so write down the new
key and keep it in a safe place to avoid exposing this secret key to
unauthorized personnel. The KeyA value is entered as a 12 hexadecimal
digit. The default KeyA is FFFFFFFFFFFF.
• The current KeyA during a new installation is the default KeyA
FFFFFFFFFFFF. For existing sites, the current KeyA is the KeyA entered the
original site installation. The current KeyA remains active until it is
changed after configuring the reader.
7. Place the Mifare
®
User Card on the CP-R25 Desktop Programmer antenna
area.
8. Click Start to start the formatting procedure.
This operation may take up to 30 seconds for a 1K card and several minutes
for a 4K card. Do not close the application or remove the card until you
receive a confirmation message.
6.2 Fingerprint Utilities
The fingerprint utility allows you to enroll fingerprints to a pre-configured User
card without changing the various information written on the card or to verify
the fingerprint written on to a card.
6.2.1 Enrolling Fingerprints on a Pre-configured User Card
The AS-B01 software allows you to enroll fingerprints onto a card already
configured with the User card ID.
To enroll fingerprints to a pre-configured user card:
1. Select the CP-R25 tab.
2. In the
Operations
area, select Finger utilities.
