AS-B01 Software Overview and LEDs
CP-R25 Hardware and AS-B01 Software Manual 19
Descriptions for fields requiring parameters under all the tabs are described in
Appendix A.
There are two programming tabs:
 Sector reader – Used to configure and read sector reader cards. This
tab allows configuring both User ID/Card Serial number user cards as
well as Reader Configuration cards.
 Swipe reader – Used to write and read cards containing fingerprint
templates. This tab also allows creating configuration cards for
fingerprint readers.
 Message log area – The event log records all activities and provides the
user with real time system monitoring. The information messages may
either be operation success or failure messages, or instruction messages
such as during fingerprint enrollment.
 Status information area – Indicates connection status with the CP-R25
Desktop Programmer hardware.
4.2 Indication LEDs
The following table describes LED behavior on the CP-R25 Programmer (see
Figure 2).
Table 1: Indication LEDs
Event Swipe Card Reader
LED
Fingerprint
Reader LED
Buzzer Fingerprint
Directional
Indication LED
General
Power on One red LED lights for several seconds followed by all the LEDs flashing and
the buzzer beeps 3 times for the duration of 3 seconds.
Card Programming
Card not
loaded
Green flashing All off Off All on
Card
loaded
On card detection,
green turns on for 1
second, then off
All off On card
detection short
beep, then off
All on
Write card
success
Green on for 3 sec All off 3 High tone
beeps
All on
Write card
fail
Red on for 3 seconds All off Long buzz All on
