Programming Cards and Tags
26 CP-R25 Hardware and AS-B01 Software Manual
5.3 Programming User Cards or Tags
In this section, both cards and tags are referred to as cards. The card
configuration type depends on what level of system security is implemented.
The cards configuration depends on the reader type used. There are two
reader types that determine what tab to use when configuring the cards:
 Sector reader – Used to configure and read sector reader cards. This tab
allows configuring both User ID/card serial number user cards as well as
reader configuration cards.
 Swipe reader – Used to write and read cards containing fingerprint
templates. The
CP-R25 tab also allows creating configuration cards for
fingerprint readers.
The AS-B01 application offers various configuration options including the
following:
 For a new Mifare
®
User Card, configuring the Card ID, card key and
fingerprint enrollment separately.
 For a previously configured Mifare
®
User Card, configuring the Card ID
and card key at the same time.
 For a previously configured Mifare
®
User Card, configuring the Card ID,
card key, and fingerprint enrollment at the same time.
Once a card is configured, the Card ID and the KeyA value can be modified, or
if required, completely wiped from the card.
5.3.1 Programming a Sector Reader User Card
The first stage of preparing a Mifare
®
sector read User Card is configuring a
card ID and card KeyA value. These two configuration values are done
simultaneously.
To program a Mifare
®
Sector Read User Card:
1. Select the Sector Reader tab.
2. In Operation Mode , select the Sector.
3. In
Card Type , select either Mifare
®
1 K or Mifare
®
4 K.
4. From the
Transmit Format dropdown menu, select the applicable
transmission format.
5. In
ID Location , select values for the Sector Number, Block Number, and
Byte Number fields.
If the Card Serial Number operation mode is being used by the organization,
no programming is available for the user card.
6. Ensure that the Operations is set to Program Card.
7. From the Operation Type dropdown menu, select Program User Card ID
+ KeyA.
